RODX中间接轴型鼓形齿式联轴器

RODX联轴器是ROD系列联轴器接轴加长型式,采用中间浮动接轴设计,适用于加大传动距离的场合。

RODX中间接轴型鼓形齿式联轴器基本参数

  • A为更换密封或者维修时内齿套需要移动的基本距离。

  • 注意DBSE是安装轴两端的距离,不是内齿法兰面的距离,设计或订货时需明确注明。

  • L1和L2的数值为推荐标准尺寸,意味着更快捷的供货。

  • 当实际需要不同时,设计选型或订货时须予以特殊确定。

规格额定扭矩扭矩(max)转速(max)基本尺寸重量接轴重量(每100mm)转动惯量每100mm接轴转动惯量润滑脂用量
NmNm1/minDD1D2D3d1-d2L1-L2SAKgKgJ(Kgm²)J(Kgm²)Kg
RODX0119003800600011082688214-5643353242.20.0180.00090.03
RODX02300059404700140104 8510517-7050365382.80.0470.00190.06
RODX036200122004400170127 10613020-9062380624.50.1170.00380.09
RODX04930018400400021015513215526-105765951046.50.290.0090.12
RODX051540031000392023518215017830-1209051101388.60.550.0120.3
RODX0625300496003850270210 17521035-142105612520213.51.130.0250.4
RODX073860076400330031024820624870-168120614028916.62.220.0560.6
RODX084880096500290033827523527585-190135815537022.33.420.0840.8
RODX0975300147800265037830625230895-216150818048026.26.10.1221.4
RODX10930001814002300400330274335105-2301758205592328.940.1722.5
RODX111661003272002100445365 305360120-252190821873036.812.250.2783.0
RODX122260004470001800508425355415130-2902201025210485425.040.5224.5
RODX132420004800001550540465368430140-2922501630019856233.050.6223.0
RODX142750005430001420580500405465160-35027016320246068.550.50.9023.6
RODX153520006960001300648546450510170-3802901634030708578.21.3354.8
RODX164400008800001200685582486550200-41032520370370095.2107.51.7115.0
RODX1756100011220001100760642520600220-450245204004255105.8150.22.1599.0
RODX1872600014520001050800684555640245-480265204205003125.32013.039.8
RODX198580001716000990840720590690275-520400204505998152.5291.24.16211.5
RODX2011000002200000930920760640742300-560410254907078173.6414.85.81311.5
RODX2113200002640000870990844704800325-600430255208600203.9588.88.33514.5
RODX22176000035200008201040895744865350-6504702555010003241.5809.411.34523.0
RODX23198000039600007701142970810905375-6805003060011942264.51091.513.6123.0
RODX242090000418000073011851015835950400-7105203063013162284.8132716.2230.0
RODX2523100004620000680123010608701035425-7705403065015720322.61768.319.9236.0
RODX2628600005720000650128011309281080450-8105703068017220376.52252.528.0238.0
RODX27418000083600005801390124010201200475-90060030725209604353315.636.5546.0
RODX285962000119240005401550137511301355500-9006703580028990562.25988.460.4257.0
RODX297975000159500004801700156012801500525-10007403589033506695.67586.695.8875.0
RODX309515000190300004001860168514301650575-12008003598036460832.59981.3132.5115.0
  • 更高的联轴器转速运行,请联系Rokee技术部门

  • 轴孔键槽按照DIN6885标准执行,若有其他要求,请特别注明

  • A值为调整联轴器外齿轴套或更换内齿密封圈所需间隙。

  • DBSE为主从动轴端面间距离而非外齿轴套之间的距离,由客户根据机组尺寸链需要自行选取。

  • 更长的外齿轴套或者任何其他性能要求均可向Rokee技术部门另行定制。

《RODX中间接轴型鼓形齿式联轴器》发布于2020年6月16日
